Position Constraint
So the first step is to write out an equation that describes the constraint. A Distance Joint should allow the two bodies to move and rotate freely, but should keep them at a certain distance from one another. In other words:
\[C = d - l\]
which says that the current distance, \(d\) and the desired distance, \(l\) must be equal to zero.
The Derivative
The next step after defining the position constraint is to perform the derivative with respect to time. This will yield us the velocity constraint.
The velocity constraint can be found/identified directly, however its encouraged that a position constraint be created first and a derivative be performed to ensure that the velocity constraint is correct.
Another reason to write out the position constraint is because it can be useful during whats called the position correction step; the step to correct position errors (drift).
First, let’s expand \(d\) in the constraint:
\[C = \|\vec{p_a} - \vec{p_b}\| - l\]
Where \(\vec{p_a}\) and \(\vec{p_b}\) are the anchor points on the respective bodies.
We can rewrite this equation changing the magnitude to:
\[C = \sqrt{(\vec{p_a} - \vec{p_b}) \cdot (\vec{p_a} - \vec{p_b})} - l\]
Since the squared magnitude of a vector is the dot product of the vector and itself. Now we perform the derivative, but first, let:
\[\vec{u} = \vec{p_a} - \vec{p_b}\]
Which gives:
\[C = \sqrt{\vec{u} \cdot \vec{u}} - l\]
And now taking the derivative (using the chain rule):
\[\frac{d(C)}{dt} = \frac{1}{2\sqrt{\vec{u} \cdot \vec{u}}}\frac{d(\vec{u} \cdot \vec{u})}{dt} - 0\]
by the chain rule again:
\[\frac{d(C)}{dt} = \frac{1}{2\sqrt{\vec{u} \cdot \vec{u}}}(\vec{u} \cdot \frac{d(\vec{u})}{dt} + \frac{d(\vec{u})}{dt} \cdot \vec{u})\]
Since the dot product is cumulative and distributive over addition:
\[\begin{align}
\frac{d(C)}{dt} &= \frac{1}{2\sqrt{\vec{u} \cdot \vec{u}}}2(\vec{u} \cdot \frac{d(\vec{u})}{dt}) \\
&= \frac{\vec{u}}{\sqrt{\vec{u} \cdot \vec{u}}}\cdot \frac{d(\vec{u})}{dt} \\
&= \vec{n} \cdot \frac{d(\vec{u})}{dt}
\end{align}\]
Note that a vector divided by the square root of its magnitude is that same vector just normalized - i.e. \(\vec{n}\). Now we know that:
\[\begin{align}
\vec{p_a} &= \vec{c_a}m_a + \vec{r_a}R_a \\
\vec{p_b} &= \vec{c_b}m_b + \vec{r_b}R_b \\
\frac{d(\vec{p_a})}{dt} &= \vec{v_a} + w_a \times \vec{r_a} \\
\frac{d(\vec{p_b})}{dt} &= \vec{v_b} + w_b \times \vec{r_b}
\end{align}\]
The derivative of a fixed length vector under a rotation frame is the cross product of the angular velocity with that fixed length vector.
Therefore:
\[\begin{align}
\frac{d(\vec{u})}{dt} &= \frac{d(\vec{p_a} - \vec{p_b})}{dt} \\
&= \frac{d(\vec{p_a})}{dt} - \frac{d(\vec{p_b})}{dt} \\
&= \vec{v_a} + w_a \times \vec{r_a} - \vec{v_b} - w_b \times \vec{r_b} \\
\end{align}\]
Giving us:
\[\frac{d(C)}{dt} = \vec{n} \cdot (\vec{v_a} + w_a \times \vec{r_a} - \vec{v_b} - w_b \times \vec{r_b})\]
Isolate The Velocities
The next step involves isolating the velocities and identifying the Jacobian. This may be confusing at first because there are two velocity variables. In fact, there are actually four, the linear and angular velocities of both bodies. To isolate the velocities we will need to employ some identities and matrix math.
The linear velocities are already isolated so we can ignore those for now. The angular velocities on the other hand have a pesky cross product. In 3D, we can use the identity that a cross product of two vectors is the same as the multiplication by a skew symmetric matrix and the other vector; see here. For 2D, we can do something similar by examining the cross product itself:
\[\begin{align}
w \times \vec{r} &= \begin{bmatrix} -wr_y \\ wr_x \end{bmatrix} \\
&= \begin{bmatrix} -r_y \\ r_x \end{bmatrix}w \\
&= R_sw
\end{align}\]
Remember that the angular velocity in 2D is a scalar.
Removing the cross products using the process above yields:
\[\frac{d(C)}{dt} = \vec{n} \cdot (\vec{v_a} + R_{sa}w_a - \vec{v_b} - R_{sb}w_b)\]
Now if we employ some matrix multiplication we can separate the velocities from the known coefficients:
\[\begin{align}
\frac{d(C)}{dt} &= \vec{n} \cdot (\vec{v_a} + R_{sa}w_a - \vec{v_b} - R_{sb}w_b) \\
&= \vec{n}^T(\vec{v_a} + R_{sa}w_a - \vec{v_b} - R_{sb}w_b) \\
&= \vec{n}^T\begin{bmatrix} I_{2x2} & R_{sa} & -I_{2x2} & -R_{sb} \end{bmatrix} \begin{bmatrix} \vec{v_a} \\ w_a \\ \vec{v_b} \\ w_b \end{bmatrix} \\
&= \begin{bmatrix} \vec{n}^T & \vec{n}^TR_{sa} & -\vec{n}^T & -\vec{n}^TR_{sb} \end{bmatrix} \begin{bmatrix} \vec{v_a} \\ w_a \\ \vec{v_b} \\ w_b \end{bmatrix}
\end{align}\]
Where \(I_{2x2}\) is just a 2x2 identity matrix.
The dot product of two vectors is the same as multiplying the transpose of the first vector with the second.
Now, by inspection, we obtain the Jacobian:
\[J = \begin{bmatrix} \vec{n}^T & \vec{n}^TR_{sa} & -\vec{n}^T & -\vec{n}^TR_{sb} \end{bmatrix}\]
Compute The K Matrix
Lastly, to solve the constraint we need to compute the values for \(A\) (I use the name \(K\)) and \(\vec{b}\):
See the “Equality Constraints” post for the derivation of the \(A\) matrix and \(\vec{b}\) vector.
\[\begin{align}
A\vec{x} &= \vec{b} \\
A &= JM^{-1}J^T \\
\vec{x} &= \vec{\lambda} \\
\vec{b} &= -J\vec{v_i}
\end{align}\]
The \(\vec{b}\) vector is fairly straight forward to compute. Therefore I’ll skip that and compute the \(K\) matrix symbolically:
\[JM^{-1}J^T = \begin{bmatrix} \vec{n}^T & \vec{n}^TR_{sa} & -\vec{n}^T & -\vec{n}^TR_{sb} \end{bmatrix}
\begin{bmatrix}
M_a^{-1} & 0 & 0 & 0\\
0 & I_a^{-1} & 0 & 0\\
0 & 0 & M_b^{-1} & 0\\
0 & 0 & 0 & I_b^{-1}
\end{bmatrix}
\begin{bmatrix} \vec{n} \\ R_{sa}^T\vec{n} \\ -\vec{n} \\ -R_{sb}^T\vec{n} \end{bmatrix}\]
Note that the transpose of a matrix of matrices is the element wise transpose. Also note that \((AB)^T = B^TA^T\).
Multiplying left to right the first two matrices we obtain:
\[JM^{-1}J^T = \begin{bmatrix} \vec{n}^TM_a^{-1} & \vec{n}^TR_{sa}I_a^{-1} & -\vec{n}^TM_b^{-1} & -\vec{n}^TR_{sb}I_b^{-1} \end{bmatrix}
\begin{bmatrix} \vec{n} \\ R_{sa}^T\vec{n} \\ -\vec{n} \\ -R_{sb}^T\vec{n} \end{bmatrix}\]
Multiplying left to right again:
\[JM^{-1}J^T = \vec{n}^TM_a^{-1}\vec{n} + \vec{n}^TR_{sa}I_a^{-1}R_{sa}^T\vec{n} + \vec{n}^TM_b^{-1}\vec{n} + \vec{n}^TR_{sb}I_b^{-1}R_{sb}^T\vec{n}\]
Moving the scalar values (\(M, I\)) to the front:
\[JM^{-1}J^T = m_a^{-1}\vec{n}^T\vec{n} + I_a^{-1}\vec{n}^TR_{sa}R_{sa}^T\vec{n} + m_b^{-1}\vec{n}^T\vec{n} + I_b^{-1}\vec{n}^TR_{sb}R_{sb}^T\vec{n}\]
Remember the inertia tensor in 2D is a scalar, therefore we can pull it out to the front of the multiplications.
Since n is normalized:
\[\vec{n}^T\vec{n} = \vec{n} \cdot \vec{n} = 1\]
We get:
\[\begin{align}
JM^{-1}J^T &= m_a^{-1} + I_a^{-1}\vec{n}^TR_{sa}R_{sa}^T\vec{n} + m_b^{-1} + I_b^{-1}\vec{n}^TR_{sb}R_{sb}^T\vec{n} \\
&= m_a^{-1} + m_b^{-1} + I_a^{-1}\vec{n}^TR_{sa}R_{sa}^T\vec{n} + I_b^{-1}\vec{n}^TR_{sb}R_{sb}^T\vec{n}
\end{align}\]
Then if we perform the matrix multiplication in the other terms:
\[\begin{align}
\vec{n}^TR_sR_s^T\vec{n} &= (-n_xr_y + n_yr_x)R_s^T\vec{n} \\
&= (-n_xr_y + n_yr_x)(-r_yn_x + r_xn_y) \\
&= (-n_xr_y + n_yr_x)(-n_xr_y + n_yr_x) \\
&= (-n_xr_y + n_yr_x)^2 \\
&= (\vec{n} \times \vec{r})^2 \\
\end{align}\]
We obtain (remember the cross product in 2D is a scalar):
\[JM^{-1}J^T = m_a^{-1} + m_b^{-1} + I_a^{-1}(\vec{n} \times \vec{r_a})^2 + I_b^{-1}(\vec{n} \times \vec{r_b})^2\]
Plug the values of the \(K\) matrix and \(\vec{b}\) vector into your linear equation solver and you will get the impulse required to satisfy the constraint.
In this post I start to look into the deep world of Constraints and Constraint Solvers. You will appreciate why I say deep, if you do a google search for constrained dynamics or constraint solvers. You will most likely be inundated with papers with lots of maths involving very large matrices. I have had to sift through a lot of papers before getting even a basic understanding. In my experience, rather than dive straight into the maths (which lot of papers tend to do), it helps to gain an intuitive understanding of what constrained dynamics is all about, then get into the maths.
In particular, I will document my exploration into the formulation of constraint equations / functions and solving such constraint equations.
What is constrained dynamics?
Unconstrained dynamics
Where you have rigid bodies moving around the screen with no restrictions of any kind, that is unconstrained dynamics. In constrained dynamics, a rigid body in 3 dimensional space has 6 degrees of freedom, as defined by the 3 components of translation (x, y, z) and 3 components of rotation. In 2 dimensions, a rigid body has 3 degrees of freedom, as defined by 2 components of translation (x, y) and rotation (θ) about an axis perpendicular to the xy plane.
Constrained dynamics
In constrast, constrained dynamics is where you have some kind of restriction on the rigid bodies’ degrees of freedom.
A simple example is a ball falling under the force of gravity and hitting the ground. When the ball hits the ground, the ball must stop (or bounce) - the ability of the ball to keep moving vertically downwards is restricted. Specifically the y-component of the body’s position is not allowed to go below zero (assuming the ground is at y = 0). This is an example of an “Inequality constraint”, in that the constraint is satisfied so long as y >= 0, but is breached if y < 0.
Typically, constraints deal with a pair of bodies.
Another example is the distance constraint, where “the distance between these two particles should not be fixed at a prescribed distance”. This is an example of a “Equality Constraint”.
Another common example is the non-penetration constraint, or contact constraint, whereby when rigid bodies collide, they are not allowed to penetrate each other, and they are made to stop or bounce off each other. This is another example of an “Inequality constranit”.
Solving Constraints
Constraint solving is the process by which we compute the corrective displacement, corrective impulses or corrective forces that, when applied to the bodies, will pull them together or push them apart, so their movement will be restricted and the rules imposed by the constraints will remain satisfied.
In the ball vs ground example, as the ball this resolving a broken constraint (ie ball’s y-position is below 0) involves:
pushing the y componentn of the position back to zero
resetting the y-component of the velocity to zero, or the ball is to bounce, set the y-component to restitution coefficient * pre-collision y-component.
What I am about to describe is a generic framework for:
- expressing a constraint as a constraint equation,
- solving the constraint equation, in order resolve the constraint
Constraint function
A constraint is defined in terms of a constraint function C, which takes the state of a pair of bodies as parameters (e.g. position and orientation) and outputs a scalar number.
We would specifically express C as a linear combination of positional properties (linear position and angular position, ie rotation, etc, ie the “state” of the body);
When the value of this function is in the acceptable range, the constraint is satisfied. If the “state” of the constraint function is composed of position properties, and we solve this “position constraint function”, it means that we are solving the constraint by directly manipulating the position properties of the bodies - this is what we did in collision resolution.
Another way of solving constraints is come up with a constraint function that takes velocity components as input (ie linear velocity, angular velocity) and then solve that. This means that we are solving the constraint by manipulating the velocity of the bodies - similar to how we have come up with collision response.
Position constraint function
In order to come up with the necessary impulse, the first thing we must do is to come up with the position constraint function. For the moment, we will keep this discussion generic, and say that the position constraint function is expressed as follows.
\(C(x) = 0\)
where x is the positional properties of the bodies (i.e. the position and rotation of the pair of bodies).
If we now take the time derivative of the above, we arrive at the velocity constraint function.
Velocity constraint function
The direct manipulation of position to satisfy a constraint. However, we are trying to resolve constraints at the velocity level.
Again, for the moment we will keep things very generic and say that we want to express the velocity constraint as follows, where J is a matrix called the Jacobian matrix and v is the relative velocity of the objects expressed as a vector (we gradually explain why).
\[\dot C = \frac{dC}{dt}=J\cdot v =0\]
This constraint function is NOT satisfied if it does NOT equal zero. We are trying to find Δv (or the impulse to change the velocity by Δv) so that the velocity constraint function does equal zero, ie:
\[\dot C = J(v+\Delta v)=0\]
Note that derivative of C will always be some linear function, i.e. the above derivative of C can be expressing the manipulation of the relative velocity in terms of matrix maths. This is the first step to understanding the world of constraint function and constraint solvers using matrix maths!
It may also help to say that the Jacobian Matrix contains the “constraint axes” along which the impulse will be applied.
Solving the Constraint function
That is all very well and interesting but how do we actually calculate the impulse necessary to solve the velocity constraint function?
The velocity constraint function was expressed as the relative velocity multiplied by the Jacobian matrix, and that the whole point of this framework is to express velocity constraint as a linear function of velocities. You can then intuitively understand that the Jacobian is the “axis” along which the impulse will be applied - for that reason, the Jacobian is sometimes referred to as expressing the “constraint axis”. Following on from this, we can say that the impulse is some multiple of the Jacobian, and therefore, the velocity delta is the impulse multiplied by the inverse mass. Again, leaving aside the detail for now, take it for granted that Δv is expressed as below.
\[\Delta v=M^{-1}J^T\lambda\]
where:
- J is a matrix referred to as the Jacobian, and
- M is a matrix referred to as the mass matrix, or the K-matrix
Effective Mass Matrix
The mass matrix, or often referred to as the K-matrix is a diagonal matrix whose elements are the masses and inertias of the bodies.
\[K=\begin{bmatrix} I_{2\times 2}m_1 &0 &0 &0 \\ 0 & I_1 & 0 & 0 \\ 0 & 0 & I_{2\times 2}m_2 &0 \\ 0 & 0 & 0 & I_2 \end{bmatrix}\]
The inverse of the above matrix is often referred to as the effective mass.
\[M^{-1}=\begin{bmatrix} m_1^{-1} &0 &0 &0 \\ 0 & I_1^{-1} & 0 & 0 \\ 0 & 0 &m_2^{-1} &0 \\ 0 & 0 & 0 & I_2^{-1} \end{bmatrix}\]
Remember that we are trying to find Δv such that:
\[\dot C:J(v+\Delta v)+b=0\]
Reinserting the Δv magic equation back into the velocity constraint function, we get
\[\dot C:J(v+M^{-1}J^T\lambda)+b=0\]
Rearranging we can arrive at a formula for lambda (a scalar) as follows:
\[\lambda = -\frac{Jv + b}{JM^{-1}J^T}\]
Now we have he magnitude of the impulse.
Recall that the impulse ats along the Jacobian and frmo that we can calculate the required change in velocity Δv.
Adjusting for position error
Solving the velocity constraint equation given above is not always enough, however. The Δv may resolve the velocity constraint. However, this will not always fix the position constraint, as we would have only eliminated the velocity break along the constraint axis. The bodies must be given a little bit of extra “oomph” along the constraint axis to satisfy not only the velocity constraint but also the position constraint. For that, we need to introduce what is referred to as bias velocity; an extra bit of impulse/velocity, if you will. The velocity constraint function then becomes:
\[\dot C: Jv+b=0\]
where b is the bias impulse, and this is based on the output from the position constraint function C(x).
If we want this error to be reduced to zero in the next timestep ∆t, the velocity needed to correct for this error is C(s) ∆t. However, we do not want the error to be removed in a single timestep. Instead, the velocity needed to correct for the position in small steps for stability reasons. The bias term is usually expressed as following:
\[b=\frac{\beta}{h}C(x)\]
where β is a value between 0 and 1 called the bias factor. The bias factor describes the amount of error that is corrected at each timestep.
This type of error correction is called Baumgarte stabilization
If you work through the same calculations as above, you will get the following expression for lambda.
\[\lambda = -\frac{Jv+b}{JM^{-1}J^{T}}\]
With this adjusted alpha, you can calculate the impulse to get the collision response required.
Preparing for the next post
Sounds like smoke and mirrors? And why so complicated? We did not actually cover how to get J..
But assuming we can…the above allows us to encode different types of constraints as a set of matrix applications in a generic form. As long as we can come up with the constraint position function, and from there, come up with the Jacobian, solve for and scale the result by the correct mass matrix, we can solve the constraint.
Having covered the fundamental laws of physics necessary (at least for linear motion) and vector maths, it is time to make a start. But we will start, very very slowly..by making balls move around the screen.
Relationship Between Position, Velocity and Acceleration
The first step to moving objects around the screen is to review the relationship between Acceleration (a), Velocity (v), and Position (p). Specifically:
Velocity is the “rate of change over time” of Position, or in mathematics speak, “time derivative” or simply the “derivative” of Position. More intuitively, Velocity is a measure of the distance travelled in a step of time.
Acceleration is the “rate of change over time” of Velocity. Or intuitively speaking, a measure of velocity changed in a step of time.
According to the above, if we know the object’s position right now (p1) and 1 second ago (p0), the velocity is the change in position - typically referred to as displacement - (dp = p1 - p0) divided by the change in time (dt) velocity (v) = dp / dt.
Similarly, acceleration (a) = change in velocity (dv) / change in time (dt).
Euler Integration
For the purposes of building a physics engine, what this means is that we can work backwards, ie if we know an object’s acceleration, we can figure out how much the velocity is supposed to change every second. And if we know the velocity, we can figure out how much the position is supposed to change every second. This is the opposite of “derivative” and is called “integration”, which you may remember from calculus lessons at school.
